WZ40-28 Backhoe Loader
- 12-Month Warranty
- Factory Direct Price
- Fast Global Shipping
- 24/7 WhatsApp Support
Operating Weight: 7.6 t
Dimensions: 7.8 × 2.1 × 3.2m
Power:85 kW
Product Details
WZ40-28 7.6-Ton 4WD Backhoe Loader
The WZ40-28 backhoe loader combines a 2.8-ton front loader, 3.6 m dumping height and 4.1 m digging depth. Powered by an 85 kW turbocharged diesel engine, its 4WD drivetrain and articulated hydraulic steering support loading, trenching and construction work across varied jobsites.
Technical Specifications
| Model | WZ40-28 |
| Operating Weight | 7,600 kg |
| Engine Power | 85 kW Turbo Diesel |
| Drive & Steering | 4WD / Articulated Steering |
| Loader Rated Load | 2,800 kg |
| Loader Bucket | 1.4 m³ |
| Max. Dump Height | 3,600 mm |
| Max. Digging Depth | 4,100 mm |
View Full Specifications▾
| Dimensions | 7,800 × 2,100 × 3,200 mm |
| Travel Speed | 35 km/h |
| Turning Radius | 5,018 mm |
| Transmission | Automatic / 4F + 4R |
| Tire Size | 16/70-24 |
| Hydraulic System | Dual Pump / 22 MPa |
| Loader Breakout Force | 38 kN |
| Backhoe Bucket | 0.35 m³ |
| Backhoe Swing Angle | 190° |
| Ground Clearance | 350 mm |
Equipment & Attachments
Machine Configuration: Articulated hydraulic steering, hub-reduction 4WD axles, automatic transmission, dual-pump hydraulic system, pilot controls, hydraulic stabilizers with locks, forward-tilting cab, reversing camera and LED work lights.
Attachment Options: Contact us to confirm available bucket sizes, hydraulic breaker compatibility and other work attachments.
Get a WZ40-28 Backhoe Loader Quote
Request WZ40-28 pricing and FOB/CIF shipping quotes for your destination port.
Choose one machine or multiple units and ask about available attachments and configurations.
Contact us via WhatsApp or the inquiry form. Share your country, quantity and intended application for a tailored offer.
Key Advantages
1. High-Dump Loader Design: A 3.6 m dumping height supports loading into elevated truck bodies and material containers.
2. Versatile Loading & Excavation: A 2.8-ton front loader and 4.1 m digging depth combine material handling and trenching in one machine.
3. Articulated 4WD Maneuverability: Hydraulic steering, heavy-duty drive axles and 350 mm ground clearance support work on uneven construction sites.
Applications
Road & Municipal Works: Trenching, drainage maintenance and backfilling.
Material Loading: Loading soil, sand and aggregates into trucks or containers.
General Construction: Excavation, utility installation and site preparation.
Note: Confirm final machine configuration, stabilizer type, attachment compatibility and shipping details before ordering.
