WZ15-26D Backhoe Loader
- 12-Month Warranty
- Factory Direct Price
- Fast Global Shipping
- 24/7 WhatsApp Support
Operating Weight: 4 t
Dimensions: 5.8 × 1.85 × 2.6m
Power: 60 kW
Product Details
WZ15-26D 4-Ton 4WD Backhoe Loader
The WZ15-26D backhoe loader combines a 1.8-ton front loader, 3.2 m dumping height and 2.4 m digging depth. Powered by a 60 kW turbocharged diesel engine, its articulated 4WD drivetrain supports material loading, utility trenching and construction work on space-limited jobsites.
Technical Specifications
| Model | WZ15-26D |
| Operating Weight | 4,000 kg |
| Engine Power | 60 kW Turbo Diesel |
| Loader Rated Load | 1,800 kg |
| Loader Bucket | 0.9 m³ |
| Max. Dump Height | 3,200 mm |
| Max. Digging Depth | 2,400 mm |
| Backhoe Bucket | 0.13 m³ |
View Full Specifications▾
| Dimensions | 5,800 × 1,850 × 2,600 mm |
| Travel Speed | 26 km/h |
| Turning Radius | 4,000 mm |
| Transmission | Automatic / 2F + 2R |
| Tire Size | 20.5-16 |
| Hydraulic Pressure | 20 MPa |
| Loader Breakout Force | 36 kN |
| Backhoe Digging Force | 28 kN |
| Max. Digging Radius | 2,500 mm |
| Backhoe Swing Angle | 180° |
Equipment & Attachments
Machine Configuration: Four-cylinder turbocharged diesel engine, articulated hydraulic steering, wheel-side reduction 4WD axles, 2F+2R automatic transmission, air brakes and a 180° backhoe swing range.
Attachment Options: Contact us to confirm compatible loader buckets, backhoe buckets and other available work attachments.
Get a WZ15-26D Backhoe Loader Quote
Request WZ15-26D pricing and FOB/CIF quotations for your destination port.
Choose one machine or multiple units and ask about available attachments and configurations.
Contact us via WhatsApp or the inquiry form. Share your country, quantity and intended application for a tailored offer.
Key Advantages
1. High-Dump Front Loader: A 3.2 m dumping height and 0.9 m³ bucket support material loading into elevated truck bodies.
2. Loading & Excavation Versatility: A 1.8-ton loader and 2.4 m digging depth support trenching, backfilling and site preparation.
3. Articulated 4WD Mobility: Hydraulic steering and wheel-side reduction axles support positioning on construction and municipal worksites.
Applications
Road & Municipal Maintenance: Roadside trenching, drainage excavation and backfilling.
Material Loading: Loading soil, sand and aggregates into trucks or containers.
Utility & Site Construction: Pipeline trenches, excavation and general site preparation.
Note: Confirm final machine configuration, attachment compatibility and shipping details before ordering.
