WZ15-10 Backhoe Loader
- 12-Month Warranty
- Factory Direct Price
- Fast Global Shipping
- 24/7 WhatsApp Support
Operating Weight: 3.2 t
Dimensions: 5.6 × 1.68 × 2.78m
Power: 37 kW
Product Details
WZ15-10 3.2-Ton Compact 4WD Backhoe Loader
The WZ15-10 compact backhoe loader combines a 1-ton front loader, 2.2 m digging depth and 37 kW diesel engine. With a 1.68 m machine width, articulated 4WD steering and automatic transmission, it is suited for loading, trenching and maintenance work in confined areas.
Technical Specifications
| Model | WZ15-10 |
| Operating Weight | 3,200 kg |
| Engine Power | 37 kW Diesel |
| Drive & Steering | 4WD / Articulated Steering |
| Loader Rated Load | 1,000 kg |
| Loader Bucket | 0.5 m³ |
| Max. Digging Depth | 2,200 mm |
| Backhoe Bucket | 0.15 m³ |
View Full Specifications▾
| Dimensions | 5,600 × 1,680 × 2,780 mm |
| Travel Speed | 20 km/h |
| Turning Radius | 3,000 mm |
| Transmission | Automatic / 2F + 2R |
| Drive Axles | Isuzu Axles |
| Hydraulic Pressure | 20 MPa |
| Loader Breakout Force | 20 kN |
| Loader Dump Height | 2,300 mm |
| Backhoe Digging Force | 15 kN |
| Backhoe Swing Angle | 170° |
Equipment & Attachments
Machine Configuration: Articulated hydraulic steering, Isuzu drive axles, 2F+2R automatic transmission, mechanical loader joystick, hydraulic backhoe joystick, hydraulic stabilizer locks, tilting cab, rotating seat and cabin heater.
Attachment Options: Contact us to confirm compatible buckets and other available attachments for your application.
Get a WZ15-10 Backhoe Loader Quote
Request WZ15-10 pricing and FOB/CIF quotations for your destination port.
Choose one machine or multiple units and ask about available attachments and configurations.
Contact us via WhatsApp or the inquiry form. Share your country, quantity and intended application for a tailored offer.
Key Advantages
1. Compact Articulated 4WD Design: A 1.68 m machine width and 3 m turning radius support operation in restricted work areas.
2. Loading & Trenching Versatility: A 1-ton loader and 2.2 m digging depth combine material handling and shallow excavation.
3. Practical Operator Controls: Separate mechanical loader and hydraulic backhoe controls support everyday construction tasks.
Applications
Municipal Maintenance: Roadside repairs, drainage trenches and backfilling.
Farm & Rural Projects: Small drainage channels, material loading and farm maintenance.
Small Construction Sites: Utility trenching, earthmoving and site preparation.
Note: Confirm final equipment configuration, attachment compatibility and shipping details before ordering.
